5. Specifications
Screen part
|
LCD screen
|
42"
|
55"
|
|
display area
|
（L）930mm（W）523mm（H）
|
（L）1210mm（W）682mm（H）
|
|
resolution
|
1920×1080
|
1920×1080
|
|
brightness
|
450cd/㎡
|
450cd/㎡
|
|
color
|
16.7M
|
16.7M
|
|
view angle
|
178°/178°
|
178°/178°
|
|
contrast ratio
|
3000:01:00
|
3000:01:00
|
|
input voltage
|
AC100-240V
|
AC100-240V
|
|
power
|
220W
|
220W
|
|
working temperature
|
0 ℃ to 50 ℃
|
0 ℃ to 50 ℃
|
|
file format
|
MPEG1/2/4,avi,MP3,JPEG
|
MPEG1/2/4,avi,MP3,JPEG
|
|
stereo
|
10W, 2X8Ω
|
10W, 2X8Ω
|
|
lifespan
|
≥60000hr
|
≥60000hr
|
|
weight
|
25-50kg
|
30-70kg
|
|
Outer color
|
silver/white/black/customized
|
silver/white/black/customized
|
|
package
|
carton+foam+ wooden support
|
carton+foam+ wooden support
|
|
accessories
|
remote control, power line, manual,
warranty card, certificate
|
remote control, power line, manual,
warranty card, certificate
|
|
others
|
built-in WIFI module
|
built-in WIFI module
|
Touch part
|
sensing method
|
Transmission type capacitor technology
with metal grid matrix instead of the ITO layer
|
|
light transmittance
|
91%
|
|
thickness
|
0.2mm
|
|
positioning accuracy
|
positioning accuracy
|
|
sensor number
|
4224
|
|
scan rate
|
>90p/1ms
|
|
supply voltage
|
5.5v
|
|
power
|
<0.5w
|
|
safety distance
|
2mm
|
|
working temperature
|
-20to +70°C
|
|
working humidity
|
0 to 95%
|
|
output interface
|
HID-usb
|
|
multi-touch
|
10 points
|
|
technical parameter
|
15mm between two fingers,finger center to
finger center,glass thickness 3-12mm,common tempered glass, AR, AG,
AF(contain no metal layer)
|
|
light resistance
|
full angle anti glare
|
|
software compatibility
|
Win7, Win8, mac, Android(need load source
code)
|
PC part
|
PC
configuration
|
mainboard
|
Mini ITX framework, Intel
H61 ，Intel H61 chipset
|
|
CPU
|
Intel I3, I5, I7,
specific models to the real product
|
|
graphic card
|
Integrated graphics, Intel（R）HD Graphics
|
|
RAM
|
DDRIII 2G/4G/8G
(optional)
|
|
HDD/SSD
|
SATA 2.5" 500G
or 32G 64G 128G SSD optional
|
|
WIFI
|
Support IEEE802.11b/g/n,
rate 150/300Mbps, Maximum 100 m indoor coverage, Support security encryption,
optional
|
-
